15BBl Professional stainless steel fermentation and brewhouse

Fermentation is one of the key parts of brewing. Therefore, it is good to know that Speidel’s fermentation tank are unique. It doesn’t matter whether they are made of synthetical material or stainless steel, with pressure or without, cylindrical, conical or oval: Speidel has the right container for every purpose. Our clever solutions, combined with the usual Speidel quality, will also convince you!

Categories: , Tags: , , , , ,

Enquiry about 15BBl Professional stainless steel fermentation and brewhouse

Description

Professional stainless steel fermentation tank for pressure-less fermentation. The double jacket allows to connect a cold water source for a controlled fermentation process. The yeast concentrates at the bottom of the cone and can be reused for future brews.

Fermentation Tank 800 liters (211 gallons)

Jacketed for cooling with conical bottom

SUS 304 Stainless Steel

Side manhole

CIP Cleaning Ball

Thermometer

Pressure Gauge

Sampling Port

Stand with adjustable legs

Mixer – 3 phase motor with shaft and paddle

15BBL Professional stainless steel fermentation tank



Model 15bbl
Working Area 2-30M2
Working voltage DC 24v
Working pressure  1.5Bar
Material Inner(SUS304),thickness: 3.0mm;
Insulation  Polyurethane-thickness 100 mm.
Temperature way Double metal thermometer
Outsourcing surface: Weld polishing processing
Heating method: Electric,steam,direct fire heating
Control system: Semi-automatic
Weight：

Adjustable
Warranty:
18 months
Outer surface: Weld polishing processing
Jacket Pressure:  design pressure 0.3 MPa, working pressure <0.2 MPa.



Packaging & Delivery

Packaging Details：
Inner:stretching PE paper and plastic membrane
Outer:wooden case or iron frame
Delivery Time：35 working days

1. This beer equipment machine is brewery for pub ,Bar，Restaurant draft .

2. Stable worktable and 20 years usage life.

3. Easy to maintain saving time and labor.

4. This machine is economy and competitive.

5.We can not only produce 100L,200L mini fermentation,but also produce 1000L,2000L

 ,3000L,5000L commercial used equipment.

6.All of our products with strict quality control before out of the factory.

Production Description

China manufacture beer brewing equipment | DEGONG

Processing type:Fermenting Equipment, Argon arc welding
Condition:New
Place of Origin:Shandong, China (Mainland)
Brand Name:DEGONGET
Model Number:DEGONG
Voltage:220V, 380V
Power(W):40Kw
Weight:1~3Tons
Certification:CE Standard for Europe, ISO9001:2000,SGS
Warranty:18 Months
After-sales Service Provided: Engineers available to service machinery overseas
Raw material: Stainless steel food grade SUS304 or 316,Red copper
Production capacity: Brewing beer 15BBL/batch
Inner surface: Mirror polishing(Roughness: Ra≤0.4um)
Heating method: Electric heating,steam heating or direct fire heating
Thickness:Inner: 3mm Outside:2mm
Control system: PLC automatic control
Cylinder cone bottom shape and dished top head
Insulation: PU foam jacket on the side and bottom(80mm)
High quality material.

To release a less than 200l of beer per day is unprofitable, so the minimum performance of our equipment is 200l.

If you are interested in our products, please contact us：
