Professional stainless steel fermentation tank for pressure-less fermentation. The double jacket allows to connect a cold water source for a controlled fermentation process. The yeast concentrates at the bottom of the cone and can be reused for future brews.
Fermentation Tank 800 liters (211 gallons)
Jacketed for cooling with conical bottom
SUS 304 Stainless Steel
CIP Cleaning Ball
Stand with adjustable legs
Mixer – 3 phase motor with shaft and paddle
15BBL Professional stainless steel fermentation tank
|Working voltage||DC 24v|
|Insulation||Polyurethane-thickness 100 mm.|
|Temperature way||Double metal thermometer|
|Outsourcing surface:||Weld polishing processing|
|Heating method:||Electric,steam,direct fire heating|
|Outer surface:||Weld polishing processing|
|Jacket Pressure:||design pressure 0.3 MPa, working pressure <0.2 MPa.|
Packaging & Delivery
- Packaging Details：
1. This beer equipment machine is brewery for pub ,Bar，Restaurant draft .
2. Stable worktable and 20 years usage life.
3. Easy to maintain saving time and labor.
4. This machine is economy and competitive.
5.We can not only produce 100L,200L mini fermentation,but also produce 1000L,2000L
,3000L,5000L commercial used equipment.
6.All of our products with strict quality control before out of the factory.
China manufacture beer brewing equipment | DEGONG
Processing type:Fermenting Equipment, Argon arc welding
Place of Origin:Shandong, China (Mainland)
Certification:CE Standard for Europe, ISO9001:2000,SGS
After-sales Service Provided: Engineers available to service machinery overseas
Raw material: Stainless steel food grade SUS304 or 316,Red copper
Production capacity: Brewing beer 15BBL/batch
Inner surface: Mirror polishing(Roughness: Ra≤0.4um)
Heating method: Electric heating,steam heating or direct fire heating
Thickness:Inner: 3mm Outside:2mm
Control system: PLC automatic control
Cylinder cone bottom shape and dished top head
Insulation: PU foam jacket on the side and bottom(80mm)
High quality material.
To release a less than 200l of beer per day is unprofitable, so the minimum performance of our equipment is 200l.
