15BBL stainless steel industrial advanced fermenter for sale

Description

15BBL stainless steel industrial commercial advanced fermenter for sale

Technical parameters

Fermenter

Material:SUS 304

1.Inner thickness:3.0mm;outer thickness:2.0mm

2.Jacket thickness:1.5mm

3.Inner surface treatment:welds grinded to Ra 0.6um

4.Mirror surface finish inside.

5.Insulation: Polyurethane-thickness 100mm

6.cone 60 degree resist compression design,dripping

7.Heat exchange area: 5.1 m2

8.Vessel pressure:1.5 bar/3.0 bar

Yeast adding tankAdopts sus 304 stainless steel fine polished process,outer stainless polishing.

Adding yeast sight glasses,aseptic air mouth,and wort pipe connection mouth.

  • Top dished head with pressure vacuum relief valve
  • Top manway or side manhole
  • Dry Hopping port with cap
  • Sanitary rotary spray ball
  • PU foam insulated
  • Cooling jacket on cylinder and cone bottom
  • The optional jacket for hot water heating in cold area to ensure good fermentation
  • Side CIP arm assembly with bung valve and pressure gauge
  • Sanitary thermowell
  • Sample Valves
  • Cone racking arm
  • 60 degree cone bottom
  • Bottom discharge
  • Four legs adjustable feet

1.Can your brewing equipment make both lager and ale?

A: Yes, our beer brewing equipment can make both lager and ale.

2.How to achieve temperature control?

A: The PLC or digital displayer could control the temperature by connecting with the PT 100 sensor. The brewing tanks with rock wool to keep warm, the fermenters and bright beer tank with PU as cooling jacket to keep cool.

3.Is it possible to supply installation in our country?

A: Yes, we could supply our clients over sea service and direct the installation and brewing.

4.What type of control system?

A: Our control system is PLC control, also pass the CE.

5.Information & certification

Degong Equipment Technology Co., Ltd. is located in Hi-tech zone, Jinan, China. Our factory covers an area of 3000 square meters or so and possesses more than 50 workers.

If you are interested in our beer fermenter,please feel free to contact me.
