2000L stainless steel fermentation tank

Fermenters are also called CCT’s (Cylindrical Conical Tanks),FV’s (Fermentation Vessel), primar fermentor or unitanks.as they are used both

for fermenting and lagering.Fermenting is the process during which the yeast transforms the wort into beer. Lager takes place after fermenting and is the time given to the beer to stabilize and age after fermenting.

Fermenters can be individually temperature controlled through glycol jackets .The design of fermenters is based on our vast beer knowledge and especially the conical fermenter bottom.

Description

2000L stainless steel fermentation tank

Fermenters are also called CCT’s (Cylindrical Conical Tanks),FV’s (Fermentation Vessel), primar fermentor or unitanks.as they are used both

for fermenting and lagering.Fermenting is the process during which the yeast transforms the wort into beer. Lager takes place after fermenting and is the time given to the beer to stabilize and age after fermenting.

Fermenters can be individually temperature controlled through glycol jackets .The design of fermenters is based on our vast beer knowledge and especially the conical fermenter bottom.









Model 2000L
Working Area 60-80M2
Working voltage DC 24v
Working pressure  1.5Bar
Material Inner(SUS304),thickness: 3.0mm;
Insulation  Polyurethane-thickness 100 mm.
Temperature way Double metal thermometer
Outsourcing surface: Weld polishing processing
Jacket Pressure:  design pressure 0.3 MPa, working pressure <0.2 MPa.

Details

1.Material Inner (SUS304)thickness: 3.0mm;

2.External-Jacket(SUS304) thickness: 1.5mm;

3.Oval head cone bottom, thickness: 3.0mm.

4.Surface: Finish    2B – cold-rolled, annealed, pickled

5.Inner surface treatment: welds grinded to

6.Ra 0.6μm (attached 360 degree Omni cleaning ball).

7.Mirror surface finish inside.

8.Insulation: Polyurethane-thickness 100 mm.



Picture of details







Double wall stainless steel tank;

Gross capacity:2450L

Useful capacity:2000L

Outer :Ø1500mm; Total height: 3200 mm

Heat exchange area:5.09㎡

Of course all details can be customized.

We are a privately held producer of beer-brewing equipment for breweries as well as hotels and restaurants. Our company lies in the capital of Shandong province which is located in North China. We have been engaged in the production for 6 years and we are devoted to quality product, reliable service, and providing a comprehensive support system for all our customers.

We can make the equipment according to customers all requirement.





If you are interested in our equipment,please feel free to get in touch with me.
