500L 1000L 1500L commercial brewing system craft freely combination brewhouse 2/3/4 vessels mash system near me

Craft freely combination brewhouse,The whole set equipment is made of SUS304 stainless steel.The cooling jacket adopts dimple jacket. The jackets are provided at tank body and conical bottom to effectively increase the cooling speed. Heat exchanging area of jacket of different proportions can be allocated according to customers’ technological requirements.


Description

Craft freely combination brewhouse advantages
  1. 1.Complete new auxiliary systems.
  2. Auxiliary systems equipment selection of leading brand and imported brand equipment.
  3. The auxiliary systems are long service life, high-performance, high-quality, low-loss.
  4. Stainless steel fittings materials are all adopt SUS304/316, applicable beer equipment to ensure the safety of food grade.
  5. 5 electrical accessories reach CE export standards.
  6. Various auxiliary systems role in the whole equipment system, supporting reliable
  7. Supporting auxiliary system voltage and frequency match exactly.
  8. Stable quality, superior performance, strict quality control.

Craft freely combination brewhousecommercial brewing system

Craft freely combination brewhouse feature

We designed and fabricate two types of 500L/1000L brewery brewhouse.

  1. Type one is 2-vessel brewhosue: mash – lauter tun and boil – whirlpool.
  2. Type two is 3-vessel as mash / boil tun, lauter tun and whirlpool.
  3. All tanks are made of SUS304 at least quality,
  4. completely polyurethane 50mm insulated,
  5. PT100 temperature sensor
  6. with control cabinet (touch panel, semi-automatic operation or full-automatic operation is optional. )and heat exchanger.
  7. All connections and fittings are equipped, completely piped and wired.
  8. Steam heating, electric heating,direct fire are available.

Craft freely combination brewhouse3-vessel brewhouse system

Craft freely combination brewhouse2-vessel brewhouse system



Hot water tank(optional)
  • circulation pump made of stainless steel
  • automatic temperature regulation
  • dry operation protection of pump
  • made of stainless steel double walled, completely insulated
  • with steam heated
  • with all connections and fittings
Craft freely combination brewhouse accessories
  • stainless steel raker
  • Lauter tank raker and wort pump with VFD ABB motor to adjust the speed. Laser cutting sieve plate with the gap 0.7mm and thickness is 4mm.
  • top glass manhole
  • Tempered Glass top manway for brewhouse.
  • Plate heat exchanger
  • Two stage type plate heat exchanger, stainless steel type.
  • sight glass
  • Glass type sight glass to make sure wort more clear during lautering
  • Stainless steel 304 operation platform

Craft freely combination brewhouse



Craft freely combination brewhouse

Craft freely combination brewhouse details

If you have interest, please feel free to contact directly.
