Automatic 30bbl brewing beer equipment manufacture Breweries

The function of beer brewhouse is processing the grist and water into the wort which is ready for fermentation. We offers varying levels of automation and customization of two, three and four vessel brew house configurations. We focus on the design and structure of the brew house, which is the reason why we have to confirm all drawings of the equipment at the first beginning.


Description

Brewing beer equipment

详情01-min

Compact brewhouse 2 vessel brewing beer equipment

We can offer 2 vessel brewery,3 vessel brewery 4 vessel brewery or custom

we plan and design complete medium-sized breweries, all systems can be designed with the client’s input for a defined process;

a variety of different vessel combinations and a number of vessels: multifunctional tanks (mash mixer – lauter, kettle – whirlpool), individual process tanks (mash mixer, lauter, boil kettle, whirlpool, hot/cold water tanks);

fully piped and wired, including valves and sensors;

integrated pump system;

CIP system: separated CIP for individual tanks to prevent cross product interference;

master brew interface control system (touch screen control panel),

staircases and platform combine the vessels in a compact unit, perforated and sectional construction of the walk-on surface ensures protection against slipping;

automated lautering, automated water mixing(option)



Brewing beer equipment-30 BBL COMPACT BREWHOUSE

(1)Mash/Lauter volume   30bbl

(1)Kettle / Whirlpool volume  30bbl

(1)Hot water tank volume  60bbl

(1)Cold water tank volume  60bbl



Design:

monoblock design, mounted on a stainless steel frame

two-vessel brewhouse (mash-lauter tun and kettle-whirlpool)

completely piped and wired

touch screen control panel

both vessels equipped with thermal oil heated bottom and jacket, insulated (option – steam heating)



mash tun-min

Add hops to kettle brewing beer equipment



brewhouse details_副本-min

Brewing beer equipment Sight glass;top manhole;rakes spent grain hatch

High quality manufacturing process:

TIG welding

laser welded pillow-plates, orbital welded pipes

automated grinding and polishing of welds and surfaces

certified materials



User friendly:

versatile process

master brew interface control system

manual control (pump on/off, flow regulation, temperature control)

organized manifold system easy accessible from the front

easy cleaning



TANK2-min

Brewery fermentation tanks

FERMENTATION TANKS

Tanks are equipped with separate cooling zones which can be individually controlled and entirely insulated. CIP tube and a cleaning head included. The materials used and the surface finishing depend on the intended application and the customers’ specifications.

  • Available in different model (from 2 to 120 bbl)
  • Material, SUS304
  • Working pressure in the glycol jacket max. 3 bar
Contact me today

Talk to us about your requirements and we will design a system to work for you and your company.
