3-Vessel Brewhouse

DEGONG 3-Vessel Brewhouses are designed to deliver best-in-class brewing quality, efficiency, yield and simplicity for today’s rapidly growing craft breweries. DEGONG standard 3-Vessel brewhouse design consists of an individual Mash Tun and Lauter Tun with an integrated Brew Kettle & Whirlpool. Utilizing DEGONG best-in-class automation & controls to maximize efficiency and versatility, these 3-Vessel systems are the perfect solution to meet your brewing needs.

DEGONG  3-Vessel Brewhouse systems are available with several options to help deliver brewing efficiency, control & automation, and overall flexibility.

Typical size range: 5 BBL, 7 BBL, 10 BBL, 15 BBL, 20 BBL, 30 BBL (custom sizing & configuration available).

Standard 3-Vessel Brewhouse configuration

High Gravity Mash Tun

Low pressure steam jacket with PLC controlled temperature control for optimum profile capability

VFD speed and function controlled, custom engineering mash mixer for low sheer, efficient mash mixing designed to handle high gravity brews

High Gravity Lauter Tun designed to handle larger grist loads

Integrated, VFD speed and function controlled rake system designed to cut and lift grain bed to maximize extract yield, reduce lautering time and automate grain out processes

Custom designed wedge wire false bottom designed to maximize yield and minimize grain pass-through

Grain out access manway for easy and efficient grain out processing

Multipoint wort collection design for uniform bed formation and high yield extract collection

Brew Kettle / Whirlpool Vessel with integrated steam jacket and temperature control

Custom designed vessel optimized for rapid boiling and efficient and high yield trub separation

Low pressure steam jacket with PLC controlled temperature control for efficient and vigorous boil control

Tangential inlet for proper centrifugal force for efficient trub separation

Semi-Automated Controls with Allen-Bradley PLC & Remote Access Support

UL Electrical System with NEMA 4X Control Panel

316L Sanitary Pumps with VFD Controls

316L Stainless Steel Plate Heat Exchanger for “Knock Out” with integrated temperature controls

Manual Sanitary Butterfly Valves

Ergonomic and efficient 304 stainless steel Brew Deck with easy access to all vessels and brewing functions.
