Ss beer Brew fermentation tank/Unitank – 10 BBL


Description

Features:(Unitank)

  • All connections are fully welded Tri Clamp fittings
  • 0.12 –0.15Mpa operating pressure; 0.3Mpa design pressure
  • Pressure gauge
  • Versitile port for dry hopping, CIP, and the pressure relief valve
  • Sampling valve
  • Thermowell for thermometer
  • Carb stone with 1/4 in ball valve
  • Blow off cane ,ball valve
  • Polyurethane insulation jacket
  • Custom ss butterfly valves with racking arm
  • Stainless lower shelf
  • Adjustable feet
  • 10BBL operating volume;  1460L max volume
  • Made from 304 stainless steel

Our 10BBL fermenter is conical shape for bottom and dished head for top, which is good for the yeast collection and tank cleaning.

Completely equipped fermenting and storage tanks, with cooling jackets, insulations, different designs of cooling system, automation of temperature and pressure.

Each fermenting and storage tank is completely manufactured from stainless steel 304, operable up to 3 bar design pressure, CE ISO TUV UL certificate, PU-insulation, cooling jackets, 360° coverage spraying ball unit. All tanks can be operated individually for different beers.

Fermentation tank/beer brew unitank detail

Material: SUS304,SUS316 or Red Copper
Appearance: SUS,Mirror SUS, Luxury Red Copper
Jacket: Dimple Plate
Insulation: Polyurethane 100mm
Heating: Electric/Steam/Direct Fire
Certification: CE,UL and ISO
Controlling System: Temperature, Pressure Auto Control/ PLC or Touch Panel
Electric Supply: 3Phase/380(220, 415,440…)v/50 (60)Hz
Single Phase/220(110, 240…)v/50(60)Hz
or as special request

Bright beer tank

When it’s time to carbonate your beer, you can rely on DG’s beer bright tanks for the job. Made of shiny and super-clean 304 Stainless Steel, you will get the results you want without the worry of external influences. Available in sizes from 1-150 BBLs and in a variety of finishes, these tanks are ready to serve.
